NIR Sensor
450 SAR 450 SAR
متوفر في المخزون
الوصف
- It detects wavelengths in the visible range at 610, 680, 730, 760, 810 and 860nm of light, each with 20nm of full-width half-max detection.
- The board also has multiple ways for you to illuminate objects that you will try to measure for a more accurate spectroscopy reading. There is an onboard LED that has been picked out specifically for this task, as well as two pins to solder your own LED into.
- 6 near-IR channels: 610nm, 680nm, 730nm, 760nm, 810nm and 860nm, each with 20nm FWHM. NIR filter set realized by silicon interference filters
- 16-bit ADC with digital access. Programmable LED drivers. 2.7V to 3.6V with I2C interface. 2x Qwiic connectors
